Running Studies

End-to-end workflow for running an SDDP study with cobre run, interpreting output, and inspecting results.

---

Preparing a Case Directory

A case directory is a folder containing all input data files required by Cobre. The minimum required structure is:

my_study/
  config.json
  penalties.json
  stages.json
  initial_conditions.json
  system/
    buses.json
    hydros.json
    thermals.json
    lines.json

All eight files are required. Before running, validate the input:

cobre validate /path/to/my_study

Successful validation prints entity counts and exits with code 0:

When validation detects errors — such as missing required fields or constraint violations — it reports them with severity labels and exits with code 1:

Fix any reported errors before proceeding. See Case Directory Format for the full schema.

---

Running cobre run

cobre run /path/to/my_study

By default, results are written to <CASE_DIR>/output/. To specify a different location:

cobre run /path/to/my_study --output /path/to/results

Lifecycle Stages

1. Load — reads input files, runs layered validation (exits code 1 on validation failure, 2 on I/O error)
2. Train — builds the SDDP policy by iterating forward/backward passes; stops when stopping rules are met
3. Simulate — (optional) evaluates the policy over independent scenarios; requires simulation.enabled = true
4. Write — writes Hive-partitioned Parquet (tabular), JSON manifests/metadata, and FlatBuffers output

---

Terminal Output

Banner

When stderr is a terminal, a banner shows the version and solver backend. Use --quiet to suppress the banner, progress bars, and post-run summary. Errors are always written to stderr regardless of --quiet.

Progress Bars

During training, a progress bar shows current iteration count. In --quiet mode, no progress bars are printed. Errors are always written to stderr.

Summary

After all stages complete, a run summary is printed to stderr with:

• Training: iteration count, convergence status, bounds, gap, cuts, solves, time
• Simulation (when enabled): scenarios requested, completed, failed
• Output directory: absolute path to results

---

Checking Results

Use cobre report to inspect the results:

cobre report /path/to/my_study/output

Reads manifest files and prints JSON to stdout (suitable for piping to jq):

cobre report /path/to/my_study/output | jq '.training.convergence.final_gap_percent'

Exits with code 0 on success or 2 if the results directory does not exist.

---

Common Workflows

Training Only

To run training without simulation, set simulation.enabled to false in config.json:

{ "simulation": { "enabled": false } }

Simulation Against a Saved Policy

To evaluate a previously trained policy without re-training:

{
  "training": { "enabled": false },
  "policy": { "mode": "warm_start", "path": "./policy" }
}

Cobre loads the policy cuts, skips training entirely, and runs simulation. See Policy Management for details on warm-start and resume modes.

Multi-threading

Use --threads to accelerate training and simulation with intra-rank parallelism:

cobre run /path/to/my_study --threads 4

The thread pool is used for forward-pass batching and simulation scenario evaluation. Speedup depends on the number of forward passes and simulation scenarios configured.

Communication Backend

A single cobre run uses the local (single-process) backend; launching under an MPI launcher (mpiexec, mpirun, or srun) distributes the work across ranks. By default (--comm-backend auto) cobre detects the launcher and selects the backend accordingly, so no flag is needed in either case. Pass --comm-backend mpi to force the MPI backend — it fails with a clear message on a binary built without MPI support — or --comm-backend local to force a single process even under a launcher.

Quiet Mode for Scripts

cobre run /path/to/my_study --quiet
exit_code=$?
if [ $exit_code -ne 0 ]; then
  echo "Study failed with exit code $exit_code" >&2
fi

Suppresses banner and progress output, suitable for batch scripts.

Checking Exit Codes

Exit Code	Meaning	Action
0	Success	Results are available in the output directory
1	Validation error	Fix the input data and re-run cobre validate
2	I/O error	Check file paths and permissions
3	Solver error	Check constraint bounds in the case data
4	Internal error	Check environment; report at the issue tracker

See CLI Reference for the full exit code table.

---

Exporting Stochastic Artifacts

Set exports.stochastic to true in config.json to write the stochastic preprocessing artifacts to output/stochastic/ before training begins:

{
  "exports": {
    "stochastic": true
  }
}

What is exported

File	Written when
output/stochastic/inflow_seasonal_stats.parquet	Estimation was performed
output/stochastic/inflow_ar_coefficients.parquet	Estimation was performed
output/stochastic/correlation.json	Always
output/stochastic/fitting_report.json	Estimation was performed
output/stochastic/noise_openings.parquet	Always
output/stochastic/load_seasonal_stats.parquet	Load buses exist

“Estimation was performed” means the user did not supply the corresponding scenario file; Cobre derived it from inflow_history.parquet.

Round-trip workflow

Because every exported file uses the exact same schema as the corresponding input file, you can copy the exported artifacts back to scenarios/ and re-run to reproduce the identical stochastic context without re-running estimation:

# Step 1: initial run with stochastic export enabled in config.json
cobre run my_case

# Step 2: copy artifacts to scenarios/
cp -r my_case/output/stochastic/* my_case/scenarios/

# Step 3: re-run — estimation is skipped, opening tree is loaded directly
cobre run my_case

The re-run is faster (no Levinson-Durbin fitting or spectral decomposition) and produces bit-for-bit identical stochastic artifacts.

For the complete schema of each exported file, see Stochastic Artifacts in the Output Format Reference.

---

See Also

• Theory: SDDP Algorithm — the forward/backward pass algorithm this workflow trains and runs.
